Standard Configurations
○ Both of the platform and side rails are made of ABS material shaped once for all.
○ Backrest is controlled by hydraulic auxiliary gas spring.
○ Height adjustable is operated by crank.
○ Dia.150mm castors with central locking system.
○ To be equipped with steering castor.
Technical features
Outer dimensions (Side rails up): L1970*W660mm（±10mm）
Mattress platform: L1930*W610mm（±10mm）
Bed height: H580-870m（±10mm）
Maximum backrest angle: ≥70°
Maximum thigh rest: ≥25°
Height of side rails(above mattress platform): 380mm（±10mm）
Safe working load: 200kgs
