Standard Configurations
1.One pair of H/F boards (B)
2.One pair of Aluminum alloy collapsible side rails
3.ABS Tuck-away crank handle system (2)
4. Molded bed board with ventilation holes
5.Stainless steel tractionframe
6.I.V Pole holes (4)
7.Drainage Hooks (2)
8.Dia.125mm castors with individual brakes (4)
Technical features
Outer dimensions (Side rails up): L2180*W1060mm（±10mm）
Mattress platform: L1960*W900mm（±10mm）
Bed height: H500mm（±10mm）
Maximum backrest angle: ≥70°
Maximum thigh rest: ≥25°
Height of side rails(above mattress platform): 380mm（±10mm）
Safe working load: 200kgs
